Automatic Toilet Paper, Towels Rewinding & Perforating Machine (6 in 1) - AM 211
Features:
* AC motor speed control.
* Step-less speed regulators.
* Automatic tail sealer.
* Pneumatic jumbo roll lifting.
* Pneumatic press cylinder at rewinding synchronized with the machine.
* Unwind stand: 1 or 2 jumbo rolls upon customer request.
* Perforating blade.
* Movement transmission by timing tension rubber belts.
* Roll opening unit by flat belts synchronized with main motor.
* Paper tear sensors. Web control
* Electrical appliances: Siemens or international brand.
Optional:
* Automatic Transfer for the Finished Logs.
Technical Features:
* Main motor: 5.5 KW or depending on machine width.
* Tail sealer motor: 0.55 KW.
* Mechanical rewinding speed: 150 - 180 m / min.
* Maximum parent roll width: 1320 mm., 1750 mm., 2400 mm. or 2650 mm.
depending on customer request.
* Parent roll outside diameter: Max. 1150 mm.
* Roll core inside diameter: 3" (76.2 mm.).
* Rewinding paper log diameter: 80 - 180 mm.
* Paper core inner diameter: 35 - 55 mm.
* Electrical supply: 380 V. & 50 Hz.
Optional:
* Automatic core feeding.
* Machine can be modified to Rewind Industrial Roll.
* Coreless rewinding system.
* Single or Double embossing unit.
